Leica MZ16 Stereo Microscope W/ 10X21B Eyepieces and PLANAPO 1.0x Objective
Included Components & Part Numbers (P/N)
Microscope Body: Leica MZ16 Zoom Optics Body (P/N: 10447102)
Features a massive 16:1 zoom ratio (0.71x – 11.5x) and built-in adjustable iris diaphragm for precise depth-of-field control.
Objective Lens: Leica PlanApo 1.0x Objective (P/N: 10472648)
Apochromatically corrected for zero color fringing, maximum brightness, and superior flatness.
Viewing Head: Leica Binocular Tube (P/N: 10445619)
Eyepieces (Pair): Leica 10x/21B Adjustable Eyepieces (P/N: 10447160)
Stand & Base: Leica Transmitted Light Stand HL with Coarse/Fine Focus Column (P/N: 10445367)
Features an integrated tilt-mirror mechanism (Clear/Matte mirror) for brightfield, darkfield, and oblique transmitted illumination.
Note: Requires an external fiber-optic cold light source & light guide (e.g., Leica KL series, 15mm/21mm optic port) to power the illumination.
Condition & Testing
Optics: Clean and clear. Smooth zoom mechanics, crisp image alignment, and crisp diopter focus.
Mechanics: Zoom control knob, iris diaphragm, and coarse/fine focus controls move smoothly throughout their entire range.
Cosmetic Condition: Good pre-owned condition with minor signs of cosmetic wear.
Leica N PLAN BD 5x 10x 20x 50x 100x ∞ /0 Infinity Objectives M32 thread, Used, In good optical condition.
Compatibility: BD (Brightfield/Darkfield) compatible.
Leica N PLAN BD 5x0.21 566077
Leica N PLAN BD 10x0.25 566005
Leica N PLAN BD 20x0.40 566029
Leica N PLAN BD 50x0.75 566030
Leica N PLAN BD 100x0.90 566031
Brand/Model: Leica Objective 1x PLAN 1.0x 10445819 M0B-211 for Stereo Microscopes
Magnification: 1.0X
M0B-211 Part No. 10445819
Thread Mount: M65
Compatibility: Designed for Leica stereo microscopes.
Working Distance (WD): 59 mm
New condition
Leica Objective HC PL APO 20x/0,75 IMM CORR CS2 506343 M25 thread
Used,in good optical condition
Product Number :11506343
Correction Ring (CORR) :CORR
Coverglass: With & without
Exit Pupil Position/DIC prism: C
Field Number (FN) :25
Free Working Distance (WD in mm): 0.66
Immersion:IMM
Iris Diaphragm : Without
Magnification : 20⨉
Contrasting Methodes : TL-BF, TL-DIC, FLUO
Numerical Aperture : 0.75
Objective Thread : M25
Objective Type : PLAN APO
Spring Loaded : Yes
Suitable for AFC (Adaptive Focus Control) : AFC suitable
Techniques : CS2, Waterdispenser
Transmission UV : (365nm)
Objective HC PL APO 20x/0,75 IMM CORR CS2 has a magnification of 20X and a numerical aperture of 0.75. For use in immersive immersion material environment and attached with an objective thread of M25 having a free working distance of 0.66mm and a FN of 25.
Leica Objective HC PL APO 93x/1,30 GLYC motCORR STED WHITE 506417
Used,in good optical condition
Product Number : 11506417Correction Ring (CORR) : motCORRCoverglass : WithExit Pupil Position/DIC prism : -Field Number (FN) : 25Free Working Distance (WD in mm) : 0.3Immersion : GLYCIris Diaphragm : WithoutMagnification : 93⨉Contrasting Methodes : TL-BF, TL-DIC, FLUONumerical Aperture : 1.3Objective Thread : M25Objective Type : PLAN APOSpring Loaded : YesSuitable for AFC (Adaptive Focus Control) : AFC suitableTechniques : CS2, MotCorr, STEDTransmission : UV (340nm)
Leica Objective HC PL APO 93x/1,30 GLYC motCORR STED WHITE 506417 has a magnification of 93X and a numerical aperture of 1.3. For use in glycerol immersion material environment and attached with an objective thread of M25 having a free working distance of 0.3mm and a FN of 25.
Brand/Model: Leica Objective PLAN APO 1.0x 10446230 1x for Stereo Microscopes
Magnification: 1.0X
Item no.:10446230
Thread Mount: M65
Compatibility: Designed for Leica stereo microscopes.
Used, in good optical condition.
Brand/Model: Leica Objective PLAN APO 1.6x 10446231 for Stereo Microscopes
Part No. 10446231
Magnification: 1.6X
Thread Mount:M65
Compatibility: Designed for Leica stereo microscopes
Used, in excellent optical condition.
Leica Objective PLANAPO 2.0x 10447101 for Stereo Microscopes
Note: There is a small chip on the extreme outer edge of the front element, but it is completely outside the effective optical path and has zero impact on imaging performance.
Part No. 10447101
Magnification: 2.0x
Thread Mount:M65
Compatibility: Designed for Leica stereo microscopes
Used, in good optical condition.
LEICA Photo/Video Tube 10446174 100%vision / 100%photo f/ MZ M stereo microscopes.
Product Name:Leica Photo/Video Tube (100% vision / 100% photo)
Part Number:10446174
Key Feature:Designed specifically for digital imaging, this tube supports100% optical image transmission, ensuring no loss of image quality when capturing photos or videos.
Compatible Microscopes:Leica MZ6 MZ7.5 MZ12.5 and other MZ M series stereo microscopes.
Used, in good optical condition.
Leica PLAN 0.5x 10446157 Stereo Microscope Objective M65 thread
Working Distance:135 mm
M65 thread
It fits for leica M /MZ series stereo microscopes
In very good optical condition.
